Automatic Tray Sealing Machine Modified Atmosphere Packaging
Machine
YiTeng Machinery
Clients want fresh food
How to meet client's demands? The MAP machines perfective find the
way to work this problem out. Our modified packaging machine series
is designed to keep food products fresh at small to medium
capacity, maximise food safety and exceed consumer's expectations.
Through a certain proportion of mixed gas of O2+ CO2 + N2, N2 +CO2 and O2+CO2 is added into the packaging to prevent or decline the food
spoilage. They are used for the packaging of meat products,
seafood, fruits, vegetables and all kinds of chilled food products.
We also can produce the sealing machine without gas flush/ vacuum
if customers don't need it. It depends on what product customer
want to pack. Please inform our salesman what function you need, if
you have any specific demand for the machine.
Related parameters:
| Product name: | Semi-auto Vacuum MAP Machine Tabletop |
| Voltage: | 110V-220V 50-60Hz / customized |
| Power: | 1600W |
| Air displacement vacuum pump: | 40 cubic meter/hour |
| Limit Vacuum: | -0.1MPA |
| Aire pressure: | 0.6Mpa |
| Dimensions: | 760*550*750mm |
| Packing speed: | 600-800 container/hour |
| N.W.: | 45kgs |
| G.W.: | 55kgs |
| Body material: | SUS304 , 6061 Aluminum alloy molds |
| Plastic tray dimensions: | 20*14cm, 18*12cm, 14*14cm, other size can be customized |
| Vacuum Pump: | 100 m³/hour |
| Air compressor: | 0.6-0.8Mpa |
| Driving mode: | Electric & pneumatic |
| Gas consumption: | 0.4 m³/min |
Main related configurations in the machine:
* Touch screen display: Shanghai FLEXEM
* Circuit breaker& transformer: Zhejiang CHINT
* Vacuum pump: ZD--Shanghai
* Temperature controller: SINNY--Zhejiang
* Motor: OUBANG-Jiangsu
* Gas mixer instrument: US Imachine/ German WITT/ YiTeng
PRODUCTS FEATURE:
1. Safety: Equipped with emergency stop; Alarm; Open-phase
protector; anti-phase protector.
2.Date printing available by installing an inkjet on top of the
machine
3.Touch screen display with PLC control system provides a
user-friendly interface.
4.The electric eye automatically tracks and corrects the sealing
position, precise alignment of film printing
5. Thermostat temperature control the sealing electric tubes.
6. The machine can install the gas mixer/vacuum pump, or if you
just need a sealing machine, we can remove these equipment.
---Tray size
* It can pack several trays at the same time, which depends on your
actual tray size.
* Above layout is just for reference. The tray size not limited in
above size.
* Accordingly to actual tray sample, the tooling of machine will be
individually built for clients.
Why Choose Us:
Wenzhou YITENG Intelligent Equipment Company is a manufacture
located in #61 Building,Times Founders Park, Mayu Town, Ruian City,
Zhejiang Province. We are specialized in the production of Filling
Machines, Sealing Machines,Labeling Machines,Capping Machines,
coding Machines, Vacuum Packing Machines, Shrink Packing
Machines,and other machines. Buying from factory the price is
competitive and it’s helpful for you to get bigger market in your
country. Factory has powerful and rich experience of technical
team. Customers can always count on us. All customers are always
allowed to customize their own modified atmosphere packaging
machine by contacting us with requirement details.
